1.6mm Thickness FR4 PCB Gas Price Display Blue LED Gas Signs
| MOQ: | 1Piece |
| Price: | USD100.0-USD350.0 |
| Standard Packaging: | Anti-vibration cotton+Carton+Wooden Case |
| Delivery Period: | 10-20 Working Days |
| Payment Method: | T/T |
| Supply Capacity: | 500PCS /Month |
1.6mm Gas Price Display
,FR4 PCB Gas Price Display
,Blue LED Gas Signs
The 1.6mm FR4 PCB Digit Electronic LED Gas Price Sign is a premium, high-performance solution designed for durability and superior visibility in demanding outdoor environments. Featuring a robust 1.6mm thick FR4 fiberglass PCB, this sign offers exceptional structural integrity and resistance to warping, moisture, and temperature fluctuations, ensuring long-term reliability in all weather conditions.
Engineered with high-intensity LED digits, the display delivers bright, uniform illumination for maximum visibility both day and night, even in direct sunlight. The UV-resistant overlay protects against fading and environmental wear, while the weatherproof housing (IP65 rated) safeguards internal components from dust, rain, and corrosion.
Ideal for modern fuel retailers, this ultra-durable, high-visibility LED sign combines cutting-edge PCB construction with advanced display technology for unmatched performance and longevity.
| Attribute | Value |
|---|---|
| LED Color | Blue Color |
| PCB Copper | 1oz |
| PCB Thickness | 1.6mm |
| Led | Ultra-wide Angle |
| Power Plug | USA/EU/CN/AUS |
| Wireless range | > 320meters |
| Assemble Method | Customized |
| DIGIT SIZE | DIGIT HEIGHT(mm) | DIGIT WIDTH(mm) | LED QTY(pcs) | VOLTAGE |
|---|---|---|---|---|
| 4'' | 124 | 75 | 42 | DC5V |
| 6'' | 161 | 103 | 64 | DC5V |
| 8'' | 201 | 119 | 98 | DC5V/12V |
| 10'' | 254 | 152 | 140 | DC5V/12V |
| 12'' | 304 | 177 | 182 | DC5V/12V |
| 15'' | 381 | 216 | 245 | DC5V/12V |
| 16'' | 412 | 235 | 350 | DC12V |
| 20'' | 500 | 281 | 434 | DC12V |
| 24'' | 600 | 350 | 581 | DC12V |
| 30'' | 750 | 438 | 840 | DC12V |
Digit Color Option (Single Color): Red /Green/Yellow/White/Blue
Digit Size Option: 4''/6''/8''/10''/12''/13''/15''/16''/20''/24''/30''
Price Format: 8.889/ 8.889/10 / 8.88/ 88.88/ 888.8/888.88...
Product Option: With Iron Steel Cabinet or Only Component
Led Brightness: 4000mcd - 9000mcd
Led Life: > 100000 hours
Digit PCB: FR4
Digit PCB Thickness: 1.6mm
Wireless Controller: Wireless Controller Remote / PC software
Communication Option: RF (470mhz / 433mhz) / RS485
Wireless Range: >250meters
Brightness Control: 6 Levels
- 1.6mm thickness
- PCB Material FR4
- Copper weight 1oz
- Thermal Stress > 288 Celsius
- Dimensional Stability, E-2/150
- Flammability Classification UL94 V0
- Water Absorption E-1/105 0.10%
- Peel Strength After thermal stress 11lb./in after 10s/288 Deg.C
- Flexural Strength 100,000 lbf/in^2 lengthwise, 75,000 lbf/in^2 crosswise
- Resistivity after damp heat volume 10^8 M ohms cm
- Resistivity after damp heat surface 10^8 M ohms
- Dielectric breakdown parallel to laminate >60KV
The 1.6mm FR4 fiberglass PCB provides the perfect balance of durability and functionality:
- Withstands extreme temperature fluctuations (-30°C to +80°C)
- Resists warping from humidity and weather exposure
- Offers superior structural support for large digit displays
- Maintains circuit integrity better than thinner PCBs
FR4 fiberglass delivers critical advantages:
- Excellent moisture resistance (＜0.1% water absorption)
- High dielectric strength for electrical safety
- Flame-retardant properties (UL94 V-0 rated)
- Superior thermal conductivity for heat dissipation
Absolutely. This thickness:
- Supports high-current LED circuits without overheating
- Provides stable power distribution for 8,000+ nits brightness
- Minimizes voltage drop across long digit segments
- Includes thermal vias for optimal heat management
The rugged FR4 design ensures:
- 10+ year lifespan in continuous outdoor use
- No corrosion or delamination issues
- Reduced need for replacements
- Easy cleaning with pressure washers (IP65 sealed)
- Compatible with automated brightness adjustment systems
